PVDF Aluminium Honeycomb Panel

Aluminium honeycomb panel is a kind of honeycomb sandwich panel,which with high weather resistance and treated by fluorocarbon spraying as surface and floor, and the middle is aluminium honeycomb core and honeycomb sandwich structure formed by high temperature and high pressure. It is characterized by light weight, high strength, sound insulation and heat insulation. Aluminium honeycomb panels are aviation and aerospace materials, and have been gradually applied in the civil field, such as construction industry, transportation industry, advertisement board and so on. SHUANGOU introduced advanced automatic continuous composite production line, using the combination of cold glue and thermal composite technology to make the product,and reach the international advanced level. At the same time, colorful panels can fully realize the perfect creativity of the architect.

SHUANGOU aluminium honeycomb panel is mainly based on high quality 3003H24 alloy aluminum plate or 5052AH14 alloy aluminum plate. The thickness of the panel is 0.8-1.5mm, the thickness of the button is 0.6-1.5MM, and the total thickness is 10mm-50mm. The core material is hexagonal 3003 type equilateral aluminum honeycomb core with aluminum foil thickness of 0.04-0.06mm and side length 5-6mm.
